7AC14F30P - 2 1/2 Ton, 14 SEER2, Air Conditioner, Single-Stage, R-454B, 208-230/1/60
Product Specifications
Product Specifications
SKU:
7AC14F30P
AHRI - Usage:
Outdoor
Brand:
Heating and Cooling
CBU - Compressor Bearing Unit:
Yes
CFM:
2,820
Color:
Gray
Compressor Type:
Scroll
Condenser Coil Fins per Inch (FPI):
22
Condenser Fan CFM:
2820
Condenser Motor HP:
1/8
Condenser Motor RPM:
825
Condenser Motor Speeds:
1
Condenser Motor Type:
PSC (Permanent Split Capacitor)
Cooling Capacity:
30,000
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Energy Star Rated:
No
Equipment Type:
Straight Cool
ERP ID:
449098
EPS:
Equipment
Full Load Amps:
0.74
Inverter:
No
Liquid Line Fitting Type:
Sweat or Braze
Liquid Line Size (OD):
3/8"
Locked Rotor Amps (LRA):
75.6
Maximum Overcurrent Protection (MOCP):
25
Maximum Piping Length:
15'
Metering Device:
TXV/TEV - Thermostatic Expansion Valve
OPT Code:
7AC14F30P
Phase:
Single
Product Family:
7AC14F
Prop 65:
Yes
Rated Load Amps (RLA):
12.7
Refrigerant:
R-454B
SEER2:
13.8-17
Sound Level (dBA):
76
Substantial Commodity:
Steel; Copper; Aluminum
Suction Line Fitting Type:
Sweat or Braze
Suction Line Size (OD):
3/4"
Tonnage:
2.5
UOM:
EA
UPC:
662551604191
Voltage:
230 VAC
Weight:
180
Product Documentation
Product Documentation
7AC14F Series 1.5 to 5 Ton Air Conditioner, Single-Stage, Omniguard® Coil, R- 454B
The 7AC14F delivers increased energy savings with efficiencies of up to 16.2 SEER2 when paired with a matched furnace or air handler.
The 7AC14F delivers increased energy savings with efficiencies of up to 16.2 SEER2 when paired with a matched furnace or air handler.
- 1.5 through 5 tons
- Sound levels as low as 73 dBA
- Single-phase power supply
- Vertical air discharge
- Applicable to indoor air handlers or gas furnaces with indoor add-on coils
- Shipped completely factory assembled, piped and wired
- Factory test operated
