7AH1AV36PX-71 - 3 Ton Air Handler, Upflow/Horizontal, Variable Speed, 1-Piece Cab, R-454B, 208-230/1/60

Product Specifications

SKU:
7AH1AV36PX-71
AHRI - Usage:
Indoor AHU
Air Flow Direction:
Upflow / Horizontal
Approvals:
AHRI, ETL Listed, CETL Listed, ISO
Blower Motor HP:
1/2
Blower Motor Speeds:
Variable
Blower Motor Type:
ECM (Electronically Commutated Motor)
Blower Wheel Diameter:
10"
Blower Wheel Width:
8"
Brand:
Heating and Cooling
Cabinet Width:
21.5
CFM:
545-1,530
Color:
Gray
Cooling Capacity:
36,000
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Drain Connection Size:
3/4"
Electric Heat Range [kW]:
0
Energy Star Rated:
No
Equipment Type:
Heat Pump
ERP ID:
449408
Evaporator Coil Fins per Inch (FPI):
15
Filter Size:
18" x 20" x 1"
EPS:
Equipment
Includes Filter Rack:
Yes
Liquid Line Fitting Type:
Sweat or Braze
Liquid Line Size (OD):
3/8"
Maximum Overcurrent Protection (MOCP):
15
Metering Device:
TXV/TEV - Thermostatic Expansion Valve
Phase:
Single
Product Family:
7AH1AV
Prop 65:
Yes
Refrigerant:
R-454B
Substantial Commodity:
Steel; Copper; Aluminum
Suction Line Fitting Type:
Sweat or Braze
Suction Line Size (OD):
7/8"
Tonnage:
3
UOM:
EA
UPC:
662551601183
Voltage:
208-230 VAC
Weight:
169

Product Documentation

7AH1AV Air Handler, Upflow/Horizontal, Variable Speed, Omniguard® Coil, TXV Furnished, R-454B Only, 60 Hz
1.5 to 5 Tons, Optional Electric Heat - 5 to 20 kW

FEATURES:
  • Omniguard ® Coil
  • Mechanical or Brazed Line Set Connections
  • Check and Expansion Valve
  • Variable Speed Blower Motor
  • Heavy Gauge Steel Cabinet
  • Anti-Microbial Dual Position Drain Pans
  • Built in Filter Rack
  • Transformer and Blower Relay
  • Electric Heat (optional)

APPLICATIONS
  • 1.5 to 5 ton nominal sizes
  • Upflow or horizontal applications
NOTE - Downflow applications require optional conversion kit.
  • Applicable to expansion valve systems in cooling applications and check and expansion valve systems in heat pump applications
  • Wide-range check and expansion valve is factory installed
  • Optional field installed electric heaters available in several sizes for additive heating capacity
