7AH2AE48PX-71 - 4 Ton Air Handler, Upflow/Horizontal, Constant Torque, 2-Piece Cab, R-454B, 208-230/1/60
Product Specifications
Product Specifications
SKU:
7AH2AE48PX-71
AHRI - Usage:
Indoor AHU
Air Flow Direction:
Upflow / Horizontal
Approvals:
• AHRI Standard 210/240-2023, NEC and CEC
Blower Motor HP:
1
Blower Motor Speeds:
Multiple
Blower Motor Type:
ECM (Electronically Commutated Motor)
Blower Wheel Diameter:
12"
Blower Wheel Width:
9
Brand:
Heating and Cooling
Cabinet Width:
21.25
CFM:
867-1,903
Color:
Gray
Cooling Capacity:
48,000
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Drain Connection Size:
3/4"
Electric Heat Range [kW]:
4-25
Energy Star Rated:
No
Equipment Type:
Heat Pump
ERP ID:
449413
Evaporator Coil Fins per Inch (FPI):
15
Filter Size:
20" x 24" x 1"
EPS:
Equipment
Includes Filter Rack:
Yes
Liquid Line Fitting Type:
Sweat or Braze
Liquid Line Size (OD):
3/8"
Maximum Overcurrent Protection (MOCP):
15
Metering Device:
TXV/TEV - Thermostatic Expansion Valve
Phase:
Single
Product Family:
7AH2AE
Prop 65:
Yes
Refrigerant:
R-454B
Stage:
1
Substantial Commodity:
Steel; Copper; Aluminum
Suction Line Fitting Type:
Sweat or Braze
Suction Line Size (OD):
7/8"
Tonnage:
4
UOM:
EA
UPC:
662551602609
Voltage:
230 VAC
Weight:
170
Product Documentation
Product Documentation
7AH2AE Air Handler, Upflow/Horizontal, Constant Torque Motor, TXV Furnished, R-454B, 60 Hz
1.5 to 5 Tons, Optional Electric Heat - 5 to 25 kW
FEATURES:
1.5 to 5 Tons, Optional Electric Heat - 5 to 25 kW
FEATURES:
- Omniguard ® Coil
- Mechanical or Brazed Line Set Connections
- Check and Expansion Valve
- Constant Torque Blower Motor
- Heavy Gauge Steel Cabinet
- Dual Position Anti-Microbial Drain Pans
- Electric Heat (optional)
- Built-in Filter Rack
