80G1UH070AE12LK - 80% AFUE UH Gas Furnace, Single Stage, 70K BTU, 14.5" W, Low NOx, 120/1/60, Refrigerant Detection-Ready
Product Specifications
Product Specifications
SKU:
80G1UH070AE12LK
AFUE:
80
AHRI - Usage:
Indoor AHU
Air Flow Direction:
Upflow / Horizontal
Blower Motor HP:
1/2 HP
Blower Motor Speeds:
Multiple
Blower Wheel Diameter:
10"
Blower Wheel Width:
10"
Brand:
Heating and Cooling
BTU Input:
66,000
BTU Output:
53,000
Cabinet Width:
14.5
CFM:
504-1,160
Color:
Gray
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Energy Star Rated:
No
Equipment Type:
Furnace
ERP ID:
457012
FER Compliant:
No
EPS:
Equipment
Fuel Type:
Natural Gas
Full Load Amps:
6.8
Furnace Type:
Gas
Gas Connection Size:
1/2"
Phase:
Single
Product Family:
80G1UHELK
Prop 65:
Yes
Substantial Commodity:
Steel; Copper; Aluminum
UOM:
EA
UPC:
662551602500
Voltage:
120 VAC
Product Documentation
Product Documentation
80G1UHELK UPFLOW / HORIZONTAL GAS FURNACE, SINGLE STAGE, LOW NOx, WITH REFRIGERANT DETECTION
The 80G1UHE(L)K gas furnace is shipped ready for installation in the upflow or horizontal right position (for horizontal left position the combustion air pressure switch must be moved). The furnace is shipped with the bottom panel in place. The bottom panel must be removed if the unit is to be installed in horizontal or upflow applications with bottom return air. The furnace is equipped for installation in natural gas applications. A conversion kit (ordered separately) is required for use in propane/LP gas applications.
INSTALLATION FEATURES
HEAT EXCHANGER DESIGN
WARRANTY
The 80G1UHE(L)K gas furnace is shipped ready for installation in the upflow or horizontal right position (for horizontal left position the combustion air pressure switch must be moved). The furnace is shipped with the bottom panel in place. The bottom panel must be removed if the unit is to be installed in horizontal or upflow applications with bottom return air. The furnace is equipped for installation in natural gas applications. A conversion kit (ordered separately) is required for use in propane/LP gas applications.
INSTALLATION FEATURES
- Left or right utility connections
- Removable floor base (upflow / horizontal units) for bottom return air
- Zero step horizontal conversion
- Upflow / Horizontal
HEAT EXCHANGER DESIGN
- Aluminized steel tapered crimped non-welded clam shell heat exchanger design
- Aluminized steel inshot burners for smooth ignition
- Compact 33” height
- Standardized widths for easy coil fit
- Multi-speed high efficiency (constant torque) blower motor
- Easily removable slide out blower design
- Enhanced cooling SEER ratings when applied with properly matched cooling equipment
- Single stage gas valve
- Durable silicon nitride ignitor
- Self diagnostics saving last 10 fault codes regardless of power interruption
- Control features electronic air cleaner and humidifier terminals
WARRANTY
- 10 year limited parts warranty / lifetime heat exchanger warranty available. See limited warranty document for details.
