80G2DF090BE16K - 80% AFUE Downflow Gas Furnace, Two Stage, 90K BTU, 17.5" W, 120/1/60, Refrigerant Detection-Ready

Product Specifications

SKU:
80G2DF090BE16K
AFUE:
80
AHRI - Usage:
Indoor AHU
Air Flow Direction:
Downflow
Approvals:
AHRI, CSA
Blower Motor HP:
3/4
Blower Motor Speeds:
Multiple
Blower Motor Type:
ECM (Electronically Commutated Motor)
Brand:
Heating and Cooling
BTU Input:
57,000-88,000
BTU Output:
46,000-69,000
Cabinet Width:
17.5
CFM:
1,600
CFM Heating:
780-1,700
Color:
Gray
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Energy Star Rated:
No
Equipment Type:
Furnace
ERP ID:
459988
EPS:
Equipment
Fuel Type:
Natural Gas or LP
Full Load Amps:
8.2
Furnace Type:
Gas
Gas Connection Size:
1/2"
Ignition Type:
Hot Surface (HSI)
Includes Filter Rack:
No
Maximum Overcurrent Protection (MOCP):
15
Phase:
Single
Product Family:
80G2E
Substantial Commodity:
Steel; Copper; Aluminum
UOM:
EA
Voltage:
120 VAC
80G2E(K) 80% TWO-STAGE CONSTANT TORQUE GAS FURNACES

CONFIGURATIONS
  • Downflow

HEAT EXCHANGER DESIGN
  • Aluminized steel primary heat exchanger with crimped nonwelded construction

BURNERS
  • Aluminized steel in shot burners for smooth ignition

CABINET CONSTRUCTION
  • Compact 33" height
  • Standardized widths for easy coil fit
  • Heat exchanger compartment is insulated to increase efficiency and reduce sound levels
  • Baked on prepainted steel cabinet finish

CONSTANT TORQUE ECM
  • Efficient blower motor
  • Easily removable slide-out blower design
  • Dynamically balanced blower wheel with resilient motor mounts for smooth and quiet operation

CONTROLS
  • Two stage gas valve
  • Integrated ignition and fan control
  • Self diagnostics saving last 10 fault codes regardless of power interruption
  • Hot surface ignition system uses silicon nitride ignitor
  • Control features 120 volt electronic air cleaner and humidifier terminals
  • Control circuit is fuse protected
  • Color coded control wiring
  • Compatible with single or two stage thermostats for heating. Two stage thermostat is recommended when installed with two stage cooling unit.

VENTING
  • 2-speed induced draft motor with stainless steel shaft, steel ball bearings, and fan cooled for long life

INSTALLATION FEATURES
  • Left or right gas and electric entry Zero step horizontal conversion Removable floor base (upflow/horizontal units) for bottom return air

WARRANTY
  • 10 year limited parts warranty / lifetime heat exchanger warranty available. See limited warranty document for details.
