95G1UH040BE12XK - 95% AFUE UH Gas Furnace, Single Stage, 40K BTU, 17.5" W, Ultra Low NOx, 120 V, Refrigerant Detection-Ready
Product Specifications
Product Specifications
SKU:
95G1UH040BE12XK
AFUE:
95
AHRI - Usage:
Indoor AHU
Air Flow Direction:
Upflow / Horizontal
Approvals:
AHRI, CSA
Blower Motor Speeds:
Multiple
Blower Motor Type:
ECM (Electronically Commutated Motor)
Brand:
Heating and Cooling
BTU Input:
40,000
BTU Output:
39,000
Cabinet Width:
17.5
CFM:
466-1,413
Color:
Gray
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Energy Star Rated:
Yes
Equipment Type:
Furnace
ERP ID:
457026
Filter Size:
16" x 25" x 1"
EPS:
Equipment
Fuel Type:
Natural Gas or LP
Full Load Amps:
6.8
Furnace Type:
Gas
Gas Connection Size:
1/2"
Ignition Type:
Hot Surface (HSI)
Includes Filter Rack:
No
Maximum Overcurrent Protection (MOCP):
15
Phase:
Single
Product Family:
95G1EXK
Prop 65:
Yes
Substantial Commodity:
Steel; Copper; Aluminum
Tonnage:
2
UOM:
EA
Voltage:
120 VAC
Weight:
122
95G1EXK SINGLE STAGE, CONSTANT TORQUE, ULTRA LOW NOX GAS FURNACE
The 95G1EXK model is a 95% AFUE gas furnace used for upflow or horizontal applications only, manufactured with aluminized steel tubular heat exchangers. 95G1EXK units are available in heating capacities of 40,000 to 100,000 Btuh and cooling applications up to 5 tons. Units are approved for installations up 7500 feet above sea level and factory equipped for use with natural gas only. The 95G1EXK is a single-stage gas furnace with high efficiency constant torque blower motor which meets the California Ultra Low Nitrogen Oxides (NOx) Standards (14ng/J) and California Seasonal Efficiency requirements. All units use a redundant gas valve to assure safety shut-off as required by C.S.A. All specifications are subject to change without notice.
CONFIGURATIONS
View full details
The 95G1EXK model is a 95% AFUE gas furnace used for upflow or horizontal applications only, manufactured with aluminized steel tubular heat exchangers. 95G1EXK units are available in heating capacities of 40,000 to 100,000 Btuh and cooling applications up to 5 tons. Units are approved for installations up 7500 feet above sea level and factory equipped for use with natural gas only. The 95G1EXK is a single-stage gas furnace with high efficiency constant torque blower motor which meets the California Ultra Low Nitrogen Oxides (NOx) Standards (14ng/J) and California Seasonal Efficiency requirements. All units use a redundant gas valve to assure safety shut-off as required by C.S.A. All specifications are subject to change without notice.
CONFIGURATIONS
- Upflow / Horizontal
- Aluminized steel, tubular primary heat exchanger. Secondary heat exchanger constructed of aluminum fins fitted to stainless steel tubes.
- Pre-mix burner provides optimal combustion to meet NOx emission requirements
- Compact 33” height
- Standardized widths for easy coil fit
- Multi-speed high efficiency (constant torque) blower motor
- Easily removable slide out blower design
- Enhanced cooling SEER ratings when applied with properly matched cooling equipment.
- Single stage gas valve
- Durable silicon nitride ignitor
- Self diagnostics saves last 10 fault codes regardless of power interruption
- Control features electronic air cleaner and humidifier terminals
- Designed certified for direct (2-pipe) and non direct (1-pipe) applications
- Easily vented with PVC pipe
- Left or right electrical connection
- Design certified for direct and non-direct vent applications
- Zero step horizontal conversion
- Removable floor base for bottom return air
- Complies with California’s South Coast Air Quality Management district Ultra Low NOx requirements
- 10 year limited parts warranty / lifetime heat exchanger warranty available. See limited warranty document for details.
