97G2DF070BV16K - 97% AFUE Downflow Gas Furnace, Two Stage, 70K BTU, 17.5" W, 120/1/60, Refrigerant Detection-Ready
Product Specifications
Product Specifications
SKU:
97G2DF070BV16K
AFUE:
97
AHRI - Usage:
Indoor AHU
Air Flow Direction:
Downflow
Approvals:
AHRI, CSA
Blower Motor HP:
3/4
Blower Motor Speeds:
Variable
Blower Motor Type:
ECM (Electronically Commutated Motor)
Blower Wheel Diameter:
11"
Blower Wheel Width:
10"
Brand:
Heating and Cooling
BTU Input:
43,000-66,000
BTU Output:
42,000-64,000
Cabinet Width:
17.5
CFM:
1,600
CFM Heating:
680-1,700
Color:
Gray
Country of Origin:
USA
Cycle/Hertz:
60 Hz
Energy Star Rated:
Yes
Equipment Type:
Furnace
ERP ID:
459989
Filter Size:
16" x 25" x 1"
EPS:
Equipment
Fuel Type:
Natural Gas or LP
Full Load Amps:
10.1
Furnace Type:
Gas
Gas Connection Size:
1/2"
Ignition Type:
Hot Surface (HSI)
Includes Filter Rack:
No
Maximum Overcurrent Protection (MOCP):
15
Phase:
Single
Product Family:
97G2VK
Prop 65:
Yes
Substantial Commodity:
Steel; Copper; Aluminum
Tonnage:
4
UOM:
EA
Voltage:
120 VAC
97G2VK TWO STAGE VARIABLE SPEED GAS FURNACE
CONFIGURATIONS
VENTING
INSTALLATION FEATURES
HEAT EXCHANGER DESIGN
CABINET CONSTRUCTION
AIR DELIVERY SYSTEM
CONTROLS
WARRANTY
View full details
CONFIGURATIONS
- Downflow
VENTING
- 2-speed induced draft motor with stainless steel shaft, steel ball bearings, and fan cooled for long life
- Vent materials for Canadian applications must comply with ULC S636
- Certified for direct vent (2-pipe) or non-direct (1-pipe) applications
- Direct vent refers to a combustion air supply intake pipe installed in conjunction with flue gas vent pipe.
INSTALLATION FEATURES
- Left or right gas and electric entry
- Zero step horizontal conversion
- Removable floor base (upflow/horizontal units) for bottom return air
- All models comply with California's South Coast Air Quality Management district Low NOx requirements
HEAT EXCHANGER DESIGN
- Aluminized steel primary heat exchanger with crimped nonwelded construction
- AL29-4C Stainless steel secondary heat exchanger
- Non-welded crimped S-curve primary heat exchanger design for maximum durability BURNERS
- Aluminized steel in shot burners for smooth ignition
- Isolated burner enclosure for quiet operation
CABINET CONSTRUCTION
- Compact 33" height
- Standardized widths for easy coil fit
- Unitized construction for cabinet integrity
- Heat exchanger compartment is insulated to increase efficiency and reduce sound levels
- Baked on pre painted steel cabinet finish
AIR DELIVERY SYSTEM
- Efficient ECM variable speed blower motor
- Motor features "soft start" and "soft stop" for quiet operation
- Active and passive dehumidification feature
- Easily removable slide-out blower design
- Dynamically balanced blower wheel with resilient motor mounts for smooth and quiet operation
CONTROLS
- Two stage gas valve
- Integrated ignition and fan control
- System Sentry™ control retains last five (5) fault codes with push button memory recall, regardless of power interruption
- Hot surface ignition system uses silicon nitride ignitor
- Control features 120 volt electronic air cleaner and humidifier terminals
- Control circuit is fuse protected
- Color coded control wiring
- Compatible with single or two stage thermostats for heating.
- Two stage thermostat is recommended when installed with two stage cooling unit.
WARRANTY
- 10 year limited parts warranty / lifetime heat exchanger warranty available. See limited warranty document for details.
